XGS-PON 10G Optical Receiver Active Node

XGS-PON 10G Optical Receiver Active Node

1.0 Cov lus qhia luv luv ntawmXGS-PON 10G Optical Receiver Active Node

SRXG-2020AW, ua haujlwm bandwidth yog 47 ~ 1000MHz. Qhov no yog ib qho kev ua tau zoo uas tsis muaj zog, tus nqi-zoo optical active receiver nrog AGC WDM, haum rau CATV FTTH Triple-Play network. Txawm siv hauv analog TV lossis digital TV. Nws muaj siab rhiab heev optical receiver raj thiab tshwj xeeb uas tsis muaj suab nrov txuam Circuit Court. Txais Sat siab kho qhov muag lub zog tuaj yeem hloov kho los ntawm PAD qib, ua si txwv cov zis, yog li SRXG-2020AW nyob rau hauv ntau qhov sib txawv ntawm qhov tau txais lub zog kho qhov muag ntawm ntxiv rau 2 ~-21dBm, muaj cov yam ntxwv zoo thiab zoo heev . Kev ua si triple, fiber ntau rau hauv tsev, siv SRXG-2020AW optical receiver uas tuaj yeem txuag tau ntau cov khoom siv kho qhov muag fiber ntau. Rau cov neeg ua haujlwm, nws tuaj yeem txo tus nqi ntawm lub tsev network zoo heev.

2.0 Khoom feature ntawmXGS-PON 10G Optical Receiver Active Node

1. Tsis tshua muaj suab nrov (3.8 feem pua ​​​​modulate, -10dBm tau txais, CNR Ntau dua lossis sib npaug li 45.3dB)

2. Dav dynamic txais optical fais fab ntau yam: nyob rau hauv Pin =-16, MER Ntau dua los yog sib npaug rau 36.1dB

3. Muaj feem xyuam rau EPON, GPON, XG-PON FTTH network

. Muaj peev xwm txuag tau ntau qhov chaw siv hluav taws xob kho qhov muag, txo cov nqi kev teeb tsa network zoo heev

5. Nyob rau hauv 47 ~ 1000MHz bandwidth, tag nrho nrog zoo flatness feature (FL Tsawg dua los yog sib npaug rau ± 0.75dB)

6. Cov ntaub ntawv hlau, muaj kev tiv thaiv rau cov khoom siv hluav taws xob optoelectronic

7. Siab tso zis ntau, tuaj yeem siv tau los ntawm ntau tus neeg siv 8. Kev siv hluav taws xob tsawg, kev ua haujlwm siab, kev ua haujlwm siab

3.0 Daim ntawv thov tseem ceebntawmXGS-PON 10G Optical Receiver Active Node

1. CATV FTTH

2. Kev koom ua ke ntawm peb lub network

3. FTTH EPON, GPON, XG-PON

4.0 Kev taw qhia txog xwm txheejntawmXGS-PON 10G Optical Receiver Active Node

1. Liab: Tsis muaj optical input lossis optical zog < -16dBm

2. Ntsuab: Optical zog ntau yam ＞-16dBm

5.0 Technical Performance index ntawmXGS-PON 10G Optical Receiver Active Node

6.0 CNR, MER DEGRADATION TABLEntawmXGS-PON 10G Optical Receiver Active Node

7.0 Ceeb toom ntawm XGS-PON 10G Optical Receiver Active Node

1. Lub hwj chim adapter rau cov khoom siv no: Input 110/220V, tso zis DC 12V(0.6A).

2. Khaws cov khoom siv kho qhov muag kom huv si, qhov txuas tsis zoo yuav ua rau cov zis RF qis dhau.

3. Yuav tsum tsis txhob kho los ntawm lawv tus kheej, kom tsis txhob muaj kev puas tsuaj ntawm cov cuab yeej.
