SR201AW mini kho qhov muag ntawm
Khoom Zaub
Sib cuam tshuam
Tsis yog | Sib cuam tshuam | Kev piav qhia |
1 | RF TAWM | RF OUT1 F txuas |
2 | RF OUT2 xaiv | |
3 | PWR | Lub hwj chim adapter chaw nres nkoj |
4 | PON | 1490 / 1310mn cov ntaub ntawv interface SC / PC (SC / APC) |
5 | Cov tswv yim kho qhov muag | 1550/1490 / 1310mn Optical tawm tswv yim SC / APC |
Nta
■1 GHz kev ua haujlwm bandwidth
■Cov kab nrig tawm tswv yim qis dua: +2 ~ -18dBm
■ Tawm cov qib nce mus txog 76dBuV (@ -15dBm zog tswv yim);
RF 2 RF Tso Tawm Xaiv tau
■Tsawg zog nojGG lt; 1.0W
Tsis
| Kev piav qhia | Tus nqi | Chav Nyob | Cov mob / Sau Ntawv | |
Cov lus qhia tshwj xeeb (Khoos Phib Tawj) | |||||
1 | Wavelength | 1550/1490/1310 | nm | Chaw nres nkoj Com | |
1490/1310 | nm | Txog ONT | |||
2 3 | Optical fais fab tswv yim ntau yam | -18～+2 | dBm | ||
AGC Ntau Yam | 0～-12 | dBm | |||
4 | Cov tswv yim kho qhov muag Rov qab poob | ≥45 | dB | ||
RF Specifications (Kev Nce Mus Los) | |||||
4 | Bandwidth | 47～1003 | MHz | ||
5 | Lub Hauv Paus | ±1.0 | dB | 47～1003MHz，Ntawm 25 ℃ | |
6 | Txoj kab nqes | 0~2.0 | dB | 47～1003MHz，Ntawm 25 ℃ | |
7 | Kub Lub Ruaj Khov | ±1.5 | dB | Hauv kev ua haujlwm kub ntau (-25 ~ +65 ℃) | |
8 | Output Level | 75±2 | dBuV | -15dBm input lub zog kho qhov muag,Cov channel channel, ib channel kev hloov kho 4.0%, hauv kev ntsuas ntawm 860 MHz kis, ntawm 25℃ | |
9 | Txhim nyog | 75 | Ohm | ||
10 | Rov Qab Yuam Kev（47～1000MHz） | ≥12 | dB | Ntawm 25 ℃ | |
11 | MET | ≥30 | dB | -15 ~ -5dBm input lub zog kho qhov muag | |
≥24 | dB | -20 ~ -16, cov tswv yim fais fab tuag | |||
12 | Lub Zog | GG lt; 1.0 | W | ||
Ib puag ncig ib puag ncig | |||||
13 | Kev khiav hauj lwm kub | -25～65 | ℃ | ||
14 | Cia Khoom Kub | -40～70 | ℃ | ||
15 | Cia Kev noo | ≤95 | ％ | Cov tsis muaj hws | |
Neeg siv Interface | |||||
16 | Hom kho qhov muag | SC / APC hauv, SC / PC Tawm | SC Xaiv, Saib ntawm daim duab4thiab5 | ||
17 | Lub hwj chim muab | DC5V / 0.5A | Sab nraud hloov kho, Saib daim duab3 | ||
18 | RF Tso Tawm | RG6 Connector | Yeem, Saib ntawm daim duab1thiab2 | ||
1 lossis 2 qhov chaw nres nkoj | |||||
19 | Qhov taw qhia kho qhov muag | Ci Liab Liab Cov xim ntsuab | Optical zog< -16dbm,=""> Optical zog> - 16dBm, ntsuab Saib ntawm daim duab6 | ||
20 | Lub tsev nyob | 90×85×25 | hli | ||
21 | Nyhav | 0.15 | kg | ||
Cov Ntaub Ntawv Tuam Txhab
Packing& Xa Khoom
Cov FAQ
1. Cov nqe lus them nqi dab tsi uas koj them?
Feem ntau, peb lees txais T / T, PayPal, Western Union, thiab Alibaba Kev Lag Luam Kev Lag Luam. Koj tuaj yeem xaiv cov nqe lus them nqi uas yuav yooj yim dua rau koj.
2. Yuav ua li cas txog lub sijhawm txhuas?
Feem ntau, yog tias muaj' s Tshuag, peb thauj khoom tsis pub dhau 3 ~ 5 hnub ua haujlwm tom qab tso nyiaj tau lees tias. Yog tias nws tawm hauv cov khoom, lub sijhawm txhuas yuav nyob ntawm.
3.Yog li cas txog kev xa khoom?
Thaum pob tau me me, peb ib txwm xaiv FedEx, DHL, TNT, thiab UPS thiab lwm yam, thaum cov khoom lag luam muaj qhov hnyav thiab ntim ntau, peb hais kom siv kev xa khoom huab cua lossis dej hiav txwv.
4. Kuv tuaj yeem tso xaj li cas?
(1) Kev sib khom lus pom zoo rau cov nqi khoom thiab cov ntsiab lus.
(2) Daim ntawv qhia Proforma yuav xa tuaj rau kev paub meej.
(3) Tom qab kev pom zoo ntawm daim ntawv them nqi proforma, tus neeg yuav khoom ua qhov tso nyiaj.
(4) Kev tsim khoom yuav pib sai sai thaum qhov kev them nyiaj tau pom zoo los ntawm peb lub txhab nyiaj.
(5) Nkoj tawm cov khoom hauv qhov kev pom zoo xa tuaj lub sijhawm.
5. Koj puas tuaj yeem ua OEM rau peb?
Yog lawm. Yog tias muaj qee qhov kev txiav txim kom muaj nuj nqis, peb tuaj yeem ua OEM suav nrog kev luam ntawv, logo, thiab tus qauv customized rau koj.
6. li cas txog qhov Warranty?
Muaj 12 lub hlis rau qhov lav. Thaum lub warranty tsis yog lub luag haujlwm rau cov uas tawg los ntawm kev tsim txom lossis kho tshiab nrog lwm hom.
Yog tias koj yog intertested thiab xav kom tau txais tus nqi tshiab thiab cov ntaub ntawv ntxiv, tsuas yog tiv tauj peb:Helena ChenEamil / Skype ： softel12@softel-optic.comWhatsapp: +86 184 5798 0817
Cim npe nrov: sr201aw mini kho qhov muag ntawm Tuam Tshoj, Tuam Tshoj, tuam ntxhab, lwm tus neeg, Hoobkas, lag luam wholesale
