8GE XOV TOOJ
8GE XOV TOOJ
FD5008 series xPON MDU cov khoom tsim tshwj xeeb rau FTTB / FTTO / POL daim ntawv thov scenarios, muab cov ntaub ntawv ntau qhov chaw nres nkoj raws li xPON network.
Cov khoom muab 1 G/EPON adaptive PON chaw nres nkoj rau uplink, 8 10/100/1000BASE-T hluav taws xob ports rau downlink, thiab txhawb PoE/PoE + muaj nuj nqi (yeem). Nws yog siv rau kev xa cov ntaub ntawv thiab tuaj yeem muab lub zog rau cov koob yees duab txuas nrog, APs thiab lwm yam terminals.
FD5008 series cov khoom lag luam muaj cov yam ntxwv ntawm kev ntseeg siab, kev pabcuam zoo (QoS) lav, kev tswj xyuas yooj yim, hloov kho tau yooj yim thiab nthuav dav, thiab kev sib txuas yooj yim. Tag nrho cov dej num thiab kev ua tau zoo ntawm cov cuab yeej ua tau raws li ITU-T / IEEE cov qauv kev pom zoo thiab cov txheej txheem thoob ntiaj teb cov kev qhia tshwj xeeb, thiab muaj kev sib raug zoo nrog lub hauv paus chaw ua haujlwm OLT ntawm cov tuam txhab tseem ceeb.
Cov yam ntxwv ua haujlwm
Ua raws li ITU-T G.984, IEEE802.3ah tus qauv
Txhawb PoE / PoE + muaj nuj nqi (yeem)
Txhawb ONU tsis siv neeg tshawb pom / txuas tshawb pom / software hloov kho tej thaj chaw deb
Txhawb ntau txoj kev sau npe ntawm SN thiab LOID + Password
Txhawb WEB / CLI / SNMP kev tswj hwm
Txhawb nqa Dynamic Bandwidth Allocation (DBA)
Txhawb AES encryption thiab decryption
Txhawb kev tshaj tawm los tiv thaiv cua daj cua dub muaj nuj nqi
Txhawb IGMP / MLD Snooping
Txhawb ACL tswj
Txhawb kev kawm MAC chaw nyob
Txhawb chaw nres nkoj raws li kev txwv ceev
Txhawb chaw nres nkoj ntws tswj
Txhawb lub voj ntes
Txhawb VLAN / VLAN Stacking / QINQ
Txhawb nqa PoE / PoE + kev tswj hwm
|
|
||
|
Itus taw qhia |
Dsau ntawv |
||
|
PWR |
Lub zog ntsuas |
On: Lub hwj huam mov rau lub cuab yeej yog qhov qub Tawm: Lub hwj huam mov rau lub cuab yeej yog qhov txawv txav |
|
|
PON |
PON Link Indicator |
Ntawm: Qhov txuas kho qhov muag tau raug tsim Tawm: Tshawb nrhiav thiab sau npe tsis tiav |
|
|
SYS |
Qhov taw qhia qhov system |
Blinking: Lub cuab yeej tau pib Tawm: Lub cuab yeej tsis khiav lossis pib |
|
|
LOS |
Lub teeb qhia taw qhia |
On: Tsis muaj optical teeb liab input los yog txawv txav optical teeb liab input Tawm: Optical teeb liab input yog qhov qub |
|
|
POE |
POE status indicator |
On (Green): PoE fais fab mov ua haujlwm Tawm: PoE fais fab mov poob |
|
|
LAN |
Network port connection indicator |
On (Blue): Qhov chaw nres nkoj network tau txuas nrog Blinking: Cov ntaub ntawv raug xa mus rau ntawm qhov chaw nres nkoj network Tawm: Lub network chaw nres nkoj tsis txuas |
|
|
PoE + LAN |
PoE + LAN qhia |
On (Cyan): chaw nres nkoj tau txuas thiab PoE ua haujlwm Blinking: Cov ntaub ntawv raug xa mus rau ntawm qhov chaw nres nkoj network Tawm: Lub network chaw nres nkoj tsis txuas |
|
|
|
|
|
|
GPON / EPON interface Tib Hom Tib Fiber GPON: FSAN G.984.2 tus qauv EPON: 1000BASE-PX20+ Symmetrical GPON: 2.488Gbps/1.244Gbps downlink/uplink EPON: 1.25Gbps downlink/uplink Lub wavelength: Transmit: 1310nm Txais: 1490nm Txais Sensitivity: GPON: -28dBm EPON: -27dBm Saturation zog: GPON: -8dBm EPON: -3dBm Fais fab kis: GPON: {{0}}.5 ~ 5dBm EPON: 0 ~ 4dBm Qhov hnyav thiab qhov ntev Dimension: 280 hli (L) x 185 hli (W) x 44 hli (H) Qhov hnyav: ib 1,62kg
|
UserILAN chaw nres nkoj RJ{0}} connector: 8 * 10/100/1000Mbps adaptive network chaw nres nkoj Full / Ib nrab Duplex Auto MDI/MDI-X Itus taw qhia PWR / PON / LOS / LAN / POE / RUN Ptus tswvCkev xav Txhawb PoE / PoE + (PSE) PSE tso zis voltage: 48V DC PoE tso zis zog: 120W Ib qhov chaw nres nkoj siab tshaj tawm lub zog: 30W Kev siv lub tshuab fais fab siab tshaj plaws:<=20W Environmental parameters Ua haujlwm kub: -10 txog 50ºC Ua haujlwm av noo: 10% ~ 90%
|
