16 hauv 1 Agile CATV Analog Modulator
AH1916AM yog 4RU khib mounted chassis uas tuaj yeem nruab 16 pieces ntawm high SAW lim tau zaus agile qauv npog 860MHz. Tsawg suab nrov tawm ntawm cov suab paj nruag ua rau qhov no 16 hauv 1 agile CATV analog modulator zoo tagnrho nyob rau hauv cov xov xwm txuas.
NTA
1.Tshuaj ntau zaus kev hloov pauv tso cai rau kev tsim cov kab tsim tawm ceev ceev
2.Txawm channel ntawm no 16 hauv 1 agile CATV analog modulator yog ywj siab kiag li. Channel configuration yog hloov tau
3.Thov cua txias rau cov cua sov ua kom sov lub neej ntev kev pab cuam
4.Ntau-hloov pauv kom tau txais kev saib xyuas channel tseem tom qab lub hwj chim poob
5.Txij-ntiv tus lej LED muab cov kev qhia ua kom sai
6. Muaj pab nyob rau hauv NTSC lossis PAL teeb tsa
TSHWJ XEEB
RF | Zaus Muaj Ntau Yam | 45 ~ 860 MHz |
Rau Cov Khoom Txuas Txuas | F Txuas | |
Output Level | 105 dBµV (Adj.) | |
Kev Taw Qhia | -20 dB | |
Kev rho tawm mus rau Chaw nres nkoj | 35 dB | |
Rov Qab Poob | ≥ 12 dB | |
Nce | + 8 dB | |
GENERAL | Lub peev xwm muaj peev xwm | 16 |
Cov lus qhia Voltage Ntau Yam | 110V lossis 220V | |
Kiv Cua Txias | 2 | |
Qhov Tau Txais | 70W (Siab Thauj Lawm) | |
Qhov ntev | 42 * 17 * 20 cm | |
Nyhav Nyhav | 9 KG (Nkaus Tes Haujlwm) | |
Kev Thauj Khoom Nyhav | 3.7 KG (Chassis Tsuas) | |
10 KG (Nkaus Tes Haujlwm) | ||
Thawv Loj | 53 * 30 * 24 cm | |
Daim Npav Khoom Siv | ||
RF | Rau cov zis zaus | 45 ~ 860 MHz yam channel |
Output Level | 103 dBµV (Adj.) | |
Rau Cov Khoom Txuas Txuas | F Txuas | |
A / V Piv | -11 ~ -18 dB (Adj.) | |
Zaus | ± 10KHz | |
Video Kev Tawm Tsam | 0.6-1.5Vp-p (87.5% Tes Taws Xob) | |
Daim Video Txuas Siv | RCA daj | |
Suab tawm tswv yim | 1Vp-p (25KHz Dev.) | |
Lub Nkag Rau Khoom Sib Txuas | Dawb RCA | |
GENERAL | Kev tsuj roj | DC 5V |
KEV CAWM XEEM
KEV CAWM XEEM | YUAV TSUM |
Txav deb ntawm buildup | Tso qhov chaw khib (1 '') nruab nrab ntawm cov khoom siv hluav taws xob tsis zoo hauv cov khoom siv |
Xyuas kom yooj yim nkag mus rau cov hlua hlau | Cia tsawg kawg ntawm 18inches nyob tom qab khoom siv khib |
Pab txhawb kev pabcuam thiab kho kom zoo | Tso cai kom muaj tsawg kawg 36 '' ntawm kev tshem tawm nyob rau hauv pem hauv ntej ntawm cov khoom siv khib |
Txav deb ntawm cov cua kub lossis cua txias | Yog tias txav tsis tau, siv lub phaj deflector |
AC lub zog hluav taws xob | Nrhav cov cuab yeej ze ze lub qhov hluav taws xob kom txaus muab lub zog rau cov khoom siv kuaj thiab khoom siv fais fab |
Kev them nyiaj yug khib | Ua qee yam kev txhawb nqa khib yog qhov tsis yeem kom txhawb nqa racks |
Lub tsev paim quav | Ceev faj ntawm dej txia mus rau cov cuab yeej los ntawm cov vuas vov tsev, cov vov tsev nkag nkag, thiab cov hws txias rau dej |
Cim npe nrov: 16 hauv 1 agile CATV analog modulator, Tuam Tshoj, tuam ntxhab, lwm tus muag khoom, Hoobkas, lag luam wholesale
