Xpon Wifi Router
Khoom Zaub
Xpon Wifi Routeradopts fiber ntau WDM thev naus laus zis nrog downlink wavelength 1550nm thiab 1490nm, uplink wavelength 1310nm.
ONT-1FE-1GE-RF-W (Xpon Wifi Router) tuaj yeem ua ke wireless ua haujlwm nrog tau raws li 802.11 n / b / g cov qauv kev tswj hwm, tsis tsuas yog muaj cov kav hlau txais sab nrauv siab ntxiv, uas qhov kis tau tus nqi nce mus txog 300Mbps, tab sis kuj Xpon Wifi Router muaj zog sib sau ua ke lub zog thiab kev pab them nqi dav dav.
Khoom Nta
GPONhom:
Kev siv ib leeg-fiber ntau, muab internet, CATV, WIFI multipleservice
Txhawb ONU nws pib-nrhiav / Txuas tshawb pom / cov chaw taws teeb ua kom zoo dua ofsoftware
Wi-Fi series ntsib 802.11 n / b / g cov txheej txheem kev paub
VLAN pob tshab, cim kev teeb tsa
EPONhom:
Kev siv ib leeg-fiber ntau, muab internet, CATV, WIFI multipleservice
Txhawb ONU nws pib-nrhiav / Txuas tshawb pom / cov chaw taws teeb ua kom zoo dua ofsoftware
Wi-Fi series ntsib 802.11 n / b / g cov txheej txheem kev paub
VLAN pob tshab, cim kev teeb tsa
(Koj tuaj yeem tau txais meej ntau dua nyob hauv qhov txuas nrog)
Cov Khoom Muag Khoom Tshwj Xeeb
Yam khoom | Tsis | |
Sib cuam tshuam | PON Kev Sib Tham | GPON / EPON hom kev yoog 1 * GPONport, FSANG.984.2standard, txhawb nqa rov qab zoo rau EPON SC / PC ib hom tshuaj me me |
CATV Kev Sib Tham | 1 RF tso zis ntau lawm F-Hom Txuas | |
Ethernet Interface | 1 * 10/100 / 1000M thiab 1 * 10 / 100M auto-negotiation Puv / ib nrab hom kev kawm RJ45 connector Auto MDI / MDI-X 100m deb | |
Lub zog cuam tshuam | 12V DC fais fab mov | |
Cov Qauv Kev Ntsuas | PON Tsis muaj nuj nqi | Wavelength: Tx 1310nm, Rx1490nm Tx Optical Zog: 0.5 ～ 5dBm Rx Hnov Zoo: -28dBm Saturation Kho Kom Zoo Nkauj: -8dBm |
Cov Ntaub Ntawv Sib Xa Xov | PON Kev Nkag Los: Downstream 2.488Gbit / ss; Kev nce toj 1.244Gbit / s Ethernet: 1000Mbps thiab 100Mbps Pob Sib Tsoo Sib Piv:< 1="" *=""> latency:<> | |
Kev Sib Txuas LusTswj | Tswj hom | Thaum hloov mus rau GPON hom, txhawb cov txheej txheem raws OMCI interface raws li txhais los ntawm ITU-T G.984.4, TR069 kev tswj chaw taws teeb thiab kev tswj hwm WEB |
Thaum hloov mus rau EPON hom, Kev Txhawb Nqa IEEE802.3 QAM, ONU tuaj yeem tswj tau los ntawm OLT, TR069 kev tswj chaw taws teeb thiab WEB tswj hwm | ||
Tswj Muaj nuj nqi | Cov xwm txheej saib, Kev tswj hwm kev teeb tsa, Tswb tswj, Log tswj | |
Lub Nta Ntawm Lub Cev | Plhaub | Yas dawb casing |
Lub Zog | Lub zog mov: DC 12V /0.6A Lub zog siv:<> | |
Cov Lus Qhia Txog Lub Cev | Yam khoom Loj ： 160mm (L) * 139.5mm (W) * 28.5mm (H) Cov khoom hnyav ： 0.35kg | |
Ib puag ncig cov Lus Qhia | Kev ua haujlwm kub: 0 txog 50ºC Cia qhov kub thiab txias: -40 txog 85ºC Kev khiav hauj lwm vaum: 10% txog 90% (Tsis xeb) Cia cov av noo: 10% txog 90% (Tsis-hws) |
WIFI Specification:
Yam khoom | Tsis | |
Kev ua tsis tau | Kev khiav hauj lwm hom | Router lossis choj |
Kev txheem txuj ci | IEEE802.11b / g / n | |
Zaus | 2.412 ~ 2.472 GHz | |
Kav hlau txais xov nce | 5dBi | |
Tus nqi them | 802.11b: 1, 2, 5.5, 11Mbps 802.11g: 6, 9, 12, 24, 36, 48, 54Mbps 802.11n: tus nqi siab 300Mbps | |
Channel | 2.4GHz Channel ： 1,2,3,4,5,6,7,8,9,10,11,12,13 | |
Tes taws los piav hom | 11b ： DSSS ： DBPSK (1Mbps), DQPSK (2Mbps), CCK (5.5 / 11Mbps) 11g ： OFDM: BPSK (6 / 9Mbps), QPSK (12 / 18Mbps), 16QAM (24 / 36Mbps) Q64QAM (48 / 54Mbps) 11n ： MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM | |
Txais rhiab | 11Mbps: ≤-90dBm 54 Mbps: ≤-76dBm HT20MCS7: ≤-73dBm HT40MCS7: ≤-70dBm | |
Hloov lub hwj chim | 802.11n: 17dBm | |
Encryption hom | AES, TKIP, WPA, WPA2, WPA-PSK / WPA2-PSK |
Ntim
Daim Ntawv Thov Network
Tuam txhab ntxiv
Cov FAQ
1. Cov nqe lus them nqi dab tsi uas koj them?
Nquag, peb lees txais T / T, PayPal, Western Union. Koj tuaj yeem xaiv cov nqe lus them nqi uas yuav yooj yim dua rau koj.
2. Yuav ua li cas txog lub sijhawm txhuas?
Kev hais lus dav dav, yog tias nws muaj nyob hauv Tshuag, peb nkoj cov khoom tsis pub dhau 3 ~ 5 hnub ua haujlwm tom qab tso nyiaj tau lees tias. Yog tsis yog, lub sijhawm ua hmoov txhuas yog nyob ntawm.
3.Yog li cas txog kev xa khoom?
Thaum pob tau me me, peb feem ntau xaiv FedEx, DHL, TNT, thiab UPS thiab lwm yam, thaum cov khoom muaj cov khoom hnyav thiab ntim ntau, peb hais kom siv kev xa khoom huab cua lossis dej hiav txwv.
4. Kuv tuaj yeem tso xaj li cas?
(1) Kev sib khom lus pom zoo rau cov nqi khoom thiab cov ntsiab lus.
(2) Daim ntawv qhia Proforma yuav xa tuaj rau kev paub meej.
(3) Tom qab kev pom zoo ntawm daim ntawv them nqi proforma, tus neeg yuav khoom ua qhov tso nyiaj.
(4) Kev tsim khoom yuav pib sai sai thaum qhov kev them nyiaj tau pom zoo los ntawm peb lub txhab nyiaj.
(5) Nkoj tawm cov khoom hauv qhov kev pom zoo xa tuaj lub sijhawm.
5. Koj puas tuaj yeem ua OEM rau peb?
Tau kawg. Yog tias muaj qee qhov kev txiav txim kom muaj nuj nqis, peb tuaj yeem ua OEM suav nrog kev luam ntawv, logo, thiab cov kev cai ntim rau koj.
6. Yuav ua li cas txog kev them nyiaj yug techinal?
Peb zoo siab los pab koj daws teeb meem techinal, yog tias koj yuav peb cov cuab yeej siv, qhov kev pabcuam no yuav tsis tau them nqi.
Yog koj muaj lus nug lossis xav tau kev pab ntau ntxiv, tsuas yog hu rau:
WhatsApp / Kab / Wechat: + 86 184 5798 0817 (Helena Chen)
Email / Skype: softel12@softel-optic.com (Helena Chen)
Cim npe nrov: xpon wifi router, Tuam Tshoj, tuam ntxhab, lwm tus neeg, Hoobkas, lag luam wholesale
