5G ONU XPON
5G ONU XPON
ONT-4GE-RFDWis tau pib tsim los ua kom muaj kev sib koom tes ntau cov kev koom ua ke xws li cov khoom siv khoos phis tawm ntawm lub network, uas belongs rau XPON HGUterminal rau FTTH / O scenario Nws teeb tsa plaub 10/100 / 1000Mbps chaw nres nkoj, WiFi (2.4G+5G) chaw nres nkoj andRFinterface uas muab cov kev pabcuam kev ceev cov ntaub ntawv thiab kev pabcuam vis dis aus zoo rau cov neeg siv.
5G tsis
Network qauv | IEEE 802.11ac |
Antennas | 2T2R, txhawb nqa MU-MIMO |
Tus nqi siab tshaj plaws txhawb nqa | 20M: 173.3Mbps 40M: 400Mps 80M: 866 .7Mbps |
Cov ntaub ntawv hom qauv | BPSK QPSK 16QAM 64QAM 256QAM |
Tso zis ntau kawg | 20dBm |
Raug channel (customizable) | 36,40,44,48,52,56,60,64,100,104, 108,112,116,120 ,124,128,132,136, 140,144,149,153,157,161,165 |
Encryption hom | WPA, WPA2, WPA / WPA2, WEP, TSIS TAU |
Encryption hom | AES, TKIP |
Interface tsis
PON interface | • ClassB + • -27dBmreceiversensitivity • Wavelength: ntws los 1310nm, nqes hav 1490nm • Txhawb WBF • Daim phiaj chaw yooj yim ntawm GEMPortand TCONT • Kev Qhia Tias Muaj Tseeb: SN / password / LOID (GPON) • Ob-txoj kev FEC (Kev xa mus ntxiv rau sab nraud) • Txhawb DBA rau SRand NSR |
Ethernet chaw nres nkoj | • Sawb raws VLAN Tag / Tag rau Ethernet chaw nres nkoj. • 1: 1VLAN / N: 1VLAN / VLANPass-hla • QinQVLAN • MACaddress txwv • MACaddress kev kawm |
WLAN | • IEEE 802.11b / g / n • 2 × 2MIMO • Kav hlau txais xov nce: 5dBi • WMM (Wi-nkaus multimedia) • Ntau yam SSIDmultiple • WPS |
RFinterface | • Txhawb txheem txheem RF interfaces • Txhawb cov ntaub ntawv hd |
Kho vajtse
Qhov ntev | 220mm x 150mm x 32mm (Tsis muaj kav hlau txais xov) |
Nyhav | 310g |
Ua haujlwm ruaj khov kev nyab xeeb | 0℃～+40℃ |
Ua haujlwm ua haujlwm kev nyab xeeb | 5% RH ～ 95% RH, tsis xau |
Lub hwj chim adaptor theem | 90V ～ 270V AC ， 50 / 60Hz |
Ntaus fais fab mov | 11V ～ 14V DC ， 1A |
Siv hluav taws xob zoo li qub | 7.5 W |
Kev siv zog ntau tshaj plaws | 18 W |
Muaj kev cuam tshuam | 1RF {{2}} 4GE+Wi-Fi (2.4G+5G) |
qhov taw qhia lub teeb | HWJ HUAM / PON / LOS / LAN / WLAN / RF |
