Huawei Gpon Olt 5608T
Huawei gpon olt 5608T
Khoom Zaub
Kev piav qhia
Huawei gpon olt 5608T SmartAX MA5600T Series OLTs sib xyaw ua ke ua haujlwm siab thiab hloov kev muaj peev xwm, muab 3.2 Tbit / s lub peev xwm loj, 960 Gbit / s hloov chaw muaj peev xwm, 512K MAC chaw nyob, thiab qhov siab tshaj ntawm 44-channel 10 GE lossis 768 GE nkag chaw nres nkoj Cov.
Cov Haujlwm Loj thiab Kev Ua Haujlwm Zoo (O& M) nrog cov software tsim rau txhua tus qauv peb uas ua tiav nrog cov kev pabcuam; txo cov khoom lag luam xav tau ntawm cov khoom seem.
Nta
Kev ntseeg siab: OLT ob-pawg sib xyaw ua ke kub rov qab, chaw taws teeb rov ua kom rov zoo (DR), txhim kho tsis muaj dab tsi, Kev Ua Haujlwm Zoo (QoS), thiab xaus-rau-kawg (E2E) kev ntseeg siab tsim
Ntau txoj kev nkag mus: suav nrog E1 cov kab ntiag tug nkag, haiv neeg TDM (CESoP / SAToP), E-LAN, thiab tsis siv neeg sib txuas IPTV cov neeg siv
Kev hloov kho yooj yim: GPON, 10G PON, thiab 40G PON faib ib qho platform, ua kom muaj kev hloov pauv yooj yim thiab txhawb nqa ultra-bandwidth nkag thiab IPv4 / IPv6 dual-stack
Tus phooj ywg ib puag ncig thiab txuag hluav taws xob tsim; idle board yeej muab tua tawm hluav taws xob, ntse tus kiv cua kom ceev nrawm ntxiv txo lub zog siv ntawm cov laug cam
Specification
| Cov Lus Qhia Tshwj Xeeb | MA5600T | MA5603T | MA5608T |
| Qhov ntev (H x W x D) | 447 mm x 490 hli x 275.8 hli | 263 mm x 442 mm x 283.2 hli | 88 mm x 442 mm x 233.5 hli |
| Kev Ua Haujlwm Ib Puag Ncig | –25 ° C rau +55 ° C | –40 ° C rau +65 ° C | –40 ° C rau +65 ° C |
| 5% RH rau 95% RH | 5% RH rau 95% RH | 5% RH rau 95% RH | |
| Lub Zog | –48V DC fais fab kev tawm tswv yim | –48V DC fais fab kev tawm tswv yim | –48V DC fais fab kev tawm tswv yim |
| Dual-lub zog muab kev tiv thaiv | Dual-lub zog muab kev tiv thaiv | Dual-lub zog muab kev tiv thaiv | |
| Kev khiav hauj lwm voltage ntau ntawm –38.4V txog –72V | Kev khiav hauj lwm voltage ntau ntawm –38.4V txog –72V | Kev khiav hauj lwm voltage ntau ntawm –38.4V txog –72V | |
| Hloov pauv peev xim - Tsheb npav nyob tom qab | 3.2 Tbit / s | 1.5 Tbit / s | 720 Gbit / s |
| Pauv Hloov Peev Xwm - Tswj Tswj | 1,920 Gbit / s | 960 Gbit / s | 512 Gbit / s |
| Kev Muaj Peev Xwm | 64 x 10G GPON | 24 x 10G GPON | 8 x 10G GPON |
| 256 x GPON | 96 x GPON | 32 x GPON | |
| 768 x GE | 288 x GE | 96 x GE | |
| Chaw nres nkoj yam | Cov chaw nres nkoj tawm: 10 GE kho qhov muag thiab GE kho qhov muag / hluav taws xob qhov chaw nres nkoj | ||
| Cov kev pabcuam chaw nres nkoj: GPON kho qhov muag chaw nres nkoj, P2P FE kho qhov muag chaw nres nkoj, P2P GE optical chaw nres nkoj, thiab Ethernet optical chaw nres nkoj | |||
| Qhov Kev Ua Haujlwm Neej | Txheej 2 / txheej 3 txoj kab-nqi xa mus los | ||
| Cov kab ke qis qis, RIP, OSPF, thiab MPLS | |||
| Cov phiaj xwm moos synchronization: BITS, E1, STM-1, Ethernet moos synchronization, 1588v2, thiab 1PPS + ToD | |||
| Qhov sib faib ntau kawg ntawm 1: 256 | |||
| Qhov ntau qhov kev ncua ntev ntawm cov khoom siv: 60 km | |||
Cov Ntaub Ntawv Tuam Txhab
Packing& Xa Khoom
Yog tias koj xav tau cov ntaub ntawv ntau ntxiv ntawm Huawei gpon olt 5608t, thov hu rau peb los ntawm:
Helena Chen
Email / Skype: softel12@softel-optic.com
WhatsApp: + 86 184 5798 0817
Cim npe nrov: huawei gpon olt 5608t, Tuam Tshoj, tuam ntxhab, lwm tus neeg, Hoobkas, lag luam wholesale
