4 Pon Ports EPON OLT
4 Pon Ports EPON OLT
4 Pon Ports EPON OLT yog 1U siab 19 nti khib mount olt. Nws yog me, yooj yim, hloov tau thiab ntawm kev ua tau zoo. Nws yog qhov tsim nyog rau kev faib tawm hauv chav hauv chav ib puag ncig me me.
OLT-E4 muab 4GE thiab 4 SFP slots sib xyaw Combo interface rau uplink, thiab 4 EPON cov chaw nres nkoj rau nqes hav dej. Nws tuaj yeem txhawb 256 ONUs hauv qab 1:64 qhov sib cais splitter.
Yam ntxwv
Lub installation yog yooj yim thiab hloov tau.
Nws ua raws IEEE802.3ah txuj
Kev Txhawb Nqa 1:64 kev faib ua feem sib cais, Kev siv qib siab ntawm cov fiber ntau
Txhawb kev xa mus deb li 20 kis lus mev
Muab L2 / L3 hloov pauv ua haujlwm
Txhawb DBA (Dynamic Bandwidth Allocation)
QoS txhawb IEEE802.1p, IP Ua Ntej, DSCP IP
ONU tsis siv neeg cim
Qhov chaw nyob MAC txwv
Muaj AES-128 encryption technology
Txhawb Nqa IGMP Snooping
Txhawb OAM
Nws Txhawb IEEE802.1x
Nws muab NMS raws li SNMP, GUI interface, thiab kev txhawb nqa hauv pab pawg thiab sab nraud tswj kev tswj hwm
Cov tsis
| Yam khoom | 4 Pon Ports EPON OLT | |
| Qhov qhib | N/A | |
| Chaw nres nkoj Uplink | Kom muaj nuj nqis | 8 |
| Tooj liab | 10/100 / 1000M nws pib-tsum, RJ45: 8pcs | |
| SFP | 4 Cov Kev Npaj Rau SFP | |
| PON Chaw nres nkoj | Kom muaj nuj nqis | 4 |
| Kev sib cuam tshuam lub cev | SFP Slots | |
| Connector Hom | 1000BASE-PX20 | |
| Sib cais feem ntau Max | 1:64 | |
| Tswj Ports | 1 * 100BASE-TX tawm sab nrauv chaw nres nkoj | |
| 1 CONSOLE chaw nres nkoj | ||
PON Chaw nres nkoj Specification | Kev Thauj Mus Deb | 20KM |
| PON qhov chaw nres nkoj nrawm | Ntsig sib xws 1.25Gbps | |
| Wavelength | 1490nm TX, 1310nm RX | |
| Khoom Txuas | SC / PC | |
| Hom Fiber | 9 / 125μm SMF | |
| TX ua fais fab | +2 ~ +7dBm | |
| Rx Rhiab | -27dBm | |
| Saturation Kho qhov muag zog | -6dBm | |
| Tswj hom | SNMP, Telnet, thiab CLI hom kev tswj hwm. | |
| Tswj lub luag haujlwm | Kiv Cua Pawg Nrhiav Kom Tau | |
| Chaw nres nkoj Kev soj ntsuam thiab kev teeb tsa kev tswj hwm; | ||
| Txheej-2 hloov kev teeb tsa xws li Vlan, Pob Tseg, RSTP, IGMP, QOS, thiab lwm yam; | ||
| EPON tswj kev ua haujlwm: DBA, ONU tso cai, ACL, QOS, thiab lwm yam; | ||
| Online ONU teeb tsa thiab kev tswj hwm | ||
| Kev tswj hwm cov neeg siv | ||
| Kev tswj tswb | ||
| Txheej-ob mus | Txhawb chaw nres nkoj VLan thiab raws tu qauv Vlan | |
| Txhawb Vlan tag / Untag, vlan pob tshab kis; | ||
| Txhawb 4096 VLAN | ||
| Txhawb nqa 802.3d pob tw | ||
| RSTP | ||
| QOS raws chaw nres nkoj, VID, TOS thiab MAC chaw nyob | ||
| IGMP Snooping | ||
| 802.x ntws tswj | ||
| Chaw nres nkoj ruaj khov kev ntsuas thiab soj ntsuam | ||
| EPON Muaj nuj nqi | Txhawb chaw nres nkoj tus nqi txwv kev txwv thiab kev tswj bandwidth; | |
| Txig nrog IEEE802.3ah Txuj Ci | ||
| Txog 20KM kis nrug | ||
| Txhawb cov ntaub ntawv encryption, pab pawg tshaj tawm, chaw nres nkoj Vlan sib cais, RSTP, thiab lwm yam. | ||
| Txhawb Dynamic Bandwidth Hloov (DBA) | ||
| Txhawb ONU nws pib-nrhiav / Txuas tshawb pom / cov chaw taws teeb hloov kho tshiab ntawm software; | ||
| Txhawb VLAN kev faib thiab cov neeg siv sib cais kom tsis txhob tshaj tawm cov cua daj cua dub; | ||
| Txhawb nqa ntau yam LLID kev teeb tsa thiab ib qho LLID | ||
| teeb .Cov neeg siv khoom txawv thiab cov kev pabcuam sib txawv tuaj yeem ua | ||
| muab QoS sib txawv los ntawm kev sib txawv ntawm LLIDchannels. | ||
| Txhawb hluav taws xob tua lub tswb ua haujlwm, yooj yim rau kev tshawb pom qhov teeb meem | ||
| Txhawb kev tshaj tawm xov tooj cua daj cua dub ua haujlwm | ||
| Txhawb kev sib cais ntawm cov chaw nres nkoj sib txawv | ||
| Txhawb ACL thiab SNMP los kho cov pob ntawv cov ntawv lim kom nruj | ||
| Kev tsim qauv tshwj xeeb rau kev cais tawm kev tiv thaiv kom tswj tau ruaj khov | ||
Txhawb cov kev ncua deb kev xam ntawm EMS online Txhawb RSTP, IGMP Pov Thawj | ||
| Qhov ntev | 442mm (L) * 315mm (W) * 44mm (H) | |
| Nyhav | 4.2KG | |
| Khoom siv fais fab | 220VAC | AC: 90V ~ 240V, 47 / 63Hz |
| -48DCDC | DC: -36V ~ -72V | |
| Kev Siv Hluav Taws Xob | 45W | |
| Kev Ua Haujlwm Ib Puag Ncig | Lub Sijhawm Ua Haujlwm Kub | -10~45℃ |
| Cia Khoom Kub | -40~85℃ | |
| Tus Txheeb Ze Xaj | 5 ~ 90% (Tsis-Txias) | |
Cov FAQ
1. Cov nqe lus them nqi dab tsi?
Feem ntau, peb lees txais T / T, PayPal, Western Union, thiab Alibaba Kev Lag Luam Kev Lag Luam. Koj tuaj yeem xaiv cov nqe lus them nqi uas yog qhov yooj yim tshaj plaws rau koj.
2.How txog qhov Warranty?
Muaj 12 lub hlis rau qhov lav.
Thaum lub warranty tsis yog lub luag haujlwm rau cov uas tawg los ntawm kev tsim txom lossis kho tshiab nrog lwm hom.
3.Yog li cas txog kev xa khoom?
Thaum pob ntawv tseem me, peb nquag xaiv FedEx, DHL, TNT, UPS thiab lwm yam. Thaum rau cov khoom lag luam ntawm hnyav hnyav thiab loj ntim, huab cua lossis xa nkoj hiav txwv yuav raug pom zoo.
