Turner ASI IP tawm tswv yim Qam Modulator

Turner ASI IP tawm tswv yim Qam Modulator yog qhov ua haujlwm siab thiab raug nqi mux-scrambling QAM modulator tsim los ntawm Softel

Xa kev nug

Khoom Taw qhia

Turner ASI IP tawm tswv yim Qam Modulator

Saib ib muag khoom

Turner, ASI, IP tswv yim Qam Modulator yog qhov ua haujlwm siab thiab raug nqi mux-scrambling QAM modulatordesigned los ntawm Softel. Turner, ASI, IP tswv yim Qam Modulator muaj ntau lub tswv yim ports nyob ntawm yeem. Tom qab multiplexing, scramblingand QAM txheej txheem txheej txheem, tom qab ntawd nws muab 4 RF tso zis ntau lawm. Kom tau raws li cov neeg siv khoom ntau txoj hauv kev, lub cuab yeej no kuj tseem nruab nrog IP chaw nres nkoj kom tawm 4 MPTS dua UDP. Nws cov qauv tsim tau yooj yim txhawb kev hloov ntawm cov qauv (demodulator) asneeded.Qhov plaub CAMs / CIs (Xaiv tau) nrog thiab BISS modules tuaj yeem descramble theprograms tawm tswv yim los ntawm 4 Tuner inputs. Nws cov qauv tsim pluggable zoo heev rau kev hloov pauv ntawm cov qauv (demodulator) raws li xav tau. Turner, ASI, IP tswv yim Qam Modulator kuj tseem cim nrog qib siab, ua haujlwm siab thiab tsis tshua muaj nqi. Qhov no yog qhov hloov tau tau rau txoj kev tshaj tawm CATV cov xov tooj cua.

Cov yam ntxwv tseem ceeb

Ntau tswv yim ports xaiv:

8 DVB-C / S / S2 FTA Tuner + 6 ASI cov tswv yim ports+256 tus IP tawm tswv yim (Cov Lus 1)

4 DVB-C / S / S2 Tuner nrog CAM+6 ASI cov chaw nres nkoj nkag (Cov Lus 2)

Kev them nyiaj yug 4 raws multiplexing+4 channel scrambling channels4 raws QAM modulating

Siab txhawb nqa DVB-C (EN300 429) thiab ITU-T J.83A / B / C

Siab txhawb nqa DVB dav dav txheej txheem txheej txheem piav qhia ETR289, simulcrypt tus qauv

ETSI 101 197 thiab ETSI 103 197

Txhawb kev kho PCR kom raug

Txhawb PSI / SI editing thiab ntxig

Zoo tshaj RF tso zis ntsuas qhov ntsuas, MER≥40db

Txhawb 4 * MPTS tso zis dua UDP

4 CAM CAM decrypt ntau cov kev pab cuam los ntawm 4 Tuner cov tswv yim (Xaiv)

Kev them nyiaj yug BISS descrambling (tsuas yog rau Version 2)

Txhawb LCD zaub thiab keyboard

Txhawb kev tswj hwm Web, Hloov kho tshiab hauv web thiab USB

Cov Lus Qhia Tshwj Xeeb

Cov lus qhia	8 DVB-C / S / S2FTATuner + 6 ASI input+256IPinputersion 1
	4 DVB-C / S / S2Tunerwith CAM +6ASIersion 2
Seem Tshooj	DVB-C	Txuj Ci	J.83A (DVB-C), J.83B, J.83C
		Input Frequency	30MHz-1000Mhz
		Txwv Tsis Pub Khw	16/32/64/128/256 QAM
	DVB-S	Input Frequency	950-2150MHz
		Tus cim tus nqi	2-45Msps
		Teeb Liab Lub Zog	-65 ~ -25dBm
		FEC Dab Tsi	1/2, 2/3, 3/4, 5/6, 7/8 QPSK
	DVB-S2	Input Frequency	950-2150MHz
		Tus cim tus nqi	QPSK 1 ~ 45Mbauds
			8PSK 2 ~ 30Mbauds
		Tus lej nqi	1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10
		Demodulation Hom	QPSK, 8PSK
Multiplexing	PIDRemapping Ntau	128per input channel
	Muaj nuj nqi	PID remapping (txiav los yog manually)
		PCR kho tau qhov tseeb
		Tsim PSI / SI cov lus ncaj qha
Khawv	Siab Tshaj Plaws CA	4
	Txuj Ci	ETSI 101 197, ETSI 103 197
	Kev Txuas Lus	Hauv zos / chaw taws teeb sib txuas
Tes taws	QAM Channel	4
	Txuj Ci	EN300 429 / ITU-T J.83A / B / C
	MET	40db
	RF zaus	30 ~ 999MHz, 1KHz ruam
	Qib RF tso zis ntau lawm	-20 ~ 0dbm (87 ~ 107 dbµV), 0.1db
	Cim Npaum Cas	5.0Msps ~ 9.0Msps, 1ksps cov kauj ruam
	Txwv Tsis Pub Khw	16/32/64/128 / 256QAM
		J.83A	J.83B	J.83C
	Txwv Tsis Pub Khw	16/32/64/128 / 256QAM	64/256 QAM	64/256 QAM
	Bandwidth	8M	6M	6M
Txheej Txheem	Chaw sib tham	LCD + tswj lub nyees khawm
	Tej thaj chaw deb	Web NMS
	tswj
	Ntws Tawm	4 * MPTS tshaj UDP tawm (RJ45, 1000M, Unicast / Multicast)
	Lus	Lus Askiv thiab Suav
	SoftwareUpgrading	Web thiab USB
Dav	Qhov Loj (W * D * H)	482mm × 300mm × 44.5mm
	Nyhav	3.7kg
	Ntsig Kub	0 ~ 45 ℃ (Kev Ua Haujlwm); -20 ~ 80 ℃ (Cia)
	Lub Zog	AC 100V ± 1050 / 60Hz;
		AC 220V ± 10%, 50 / 60HZ
	Qhov Tau Txais	25W
