50 OHM Leaky Cable
50 OHM Leaky Cable
Leaky coaxial cable muaj ob qho chaw ntsuas hluav taws xob thiab cov kav hlau txais xov. Los ntawm kev tswj hwm qhib ntawm tus thawj coj sab nraud, cov kev tswj hwm hluav taws xob tuaj yeem ua tau cov kab hluav taws xob, npog thaj tsam dig muag, thiab
ua tiav lub hom phiaj ntawm kev sib txuas lus du.
Qhov zoo tshaj plaws-muag 50ohm leaky cable muaj cov qauv hauv qab no: 1\/2 "{" d, {16 "d, 1\/2" h, 7\/8 "h, 1-1 \/ 4 "h.
Daim Ntawv Thov 50 Ohm Leaky Cable:
1. Kev sib txuas lus mobile nyob rau hauv cov tuam tsev, ntau thiab subways (GSM, PCN \/ Pcs, quav ...)
2. Kev sib txuas lus hauv cov vaj tse hauv av, xws li chaw nres tsheb, hauv paus thiab cov mines
3. Kev kis tus FM pawg (88-108 mhz) cov ntaub ntawv hauv kev loj hauv kev loj
4. Xa tawm ntawm Wireless Lub tswb Cim hauv Kev Loj Hlob
5. Kev kis ntawm lub xov tooj txawb xov tooj hauv txoj kev loj
6. Kev Nkag Mus Sib Kis hauv subways lossis subway tunnels
Cov Khoom Qhia Ntawv Lom Zem
|
Kev tsa tsev Specifilub tshuab(lub hli) |
1/2"C |
7/8"C |
1-1/4"C |
1-5/8"C |
|
|
① Cov neeg coj sab hauv |
1\/2 "C: Tooj liab Clad Aluminium 7\/8" C: du tooj liab raj {{0 {0}} \/ 4 "c, {1-5 \/ 8" C: Helical Corrugated Tooj Tooj |
4.80±0.05 |
9.30±0.20 |
13.00±0.20 |
17.80±0.30 |
|
② dielectric |
Ua npuas ncauj pe |
12.30±0.20 |
22.80±0.30 |
32.50±0.30 |
42.80±0.30 |
|
GUTER OTER LUB CEV |
Tshaj tawm tooj liab ntawv nyiaj |
13.00±0.40 |
23.50±0.50 |
33.20±0.50 |
43.80±0.50 |
|
Lub tsho loj |
PE lossis LSZH |
15.50±0.40 |
27.00±0.50 |
37.20±0.50 |
47.60±0.50 |
|
Hluav taws xob Tus yam ntxwvkoob & 2011 thiab ib puag ncig Cov yam ntxwv |
|||||
|
Tus yam ntxwv cuam tshuam (ω) |
50±2 |
50±2 |
50±2 |
50±2 |
|
|
Velocity of Propagation (%) |
88 |
89 |
89 |
89 |
|
|
Capacitance (PF \/ M) |
76.0 |
75.0 |
75.0 |
75.0 |
|
|
Rwb thaiv tsev tsis kam, min (mω • km) |
10000 |
10000 |
10000 |
10000 |
|
|
Tsho Ntsuas Hluav Taws Xob Ntsuas Voltage [KV (AC)] |
8 |
8 |
10 |
10 |
|
|
Rwb thaiv tsev Voltage [KV (DC, 1min)] |
6 |
10 |
10 |
15 |
|
|
Kev khiav hauj lwm zaus (MHz) |
5-2700 |
5-2700 |
5-2700 |
5-2700 |
|
|
Qhov zoo tshaj plaws kev ua haujlwm ntau (MHz) |
700-2700 |
700-2700 |
700-2700 |
700-2700 |
|
|
Txwv tsis pub ua haujlwm zaus (MHz) |
1085-1150 |
1085-1150 |
1085-1150 |
1085-1150 |
|
|
2170-2300 |
2170-2300 |
2170-2300 |
2170-2300 |
||
|
Vswr max |
75-150 mhz |
1.30 |
1.30 |
1.30 |
1.30 |
|
300-500 mhz |
1.30 |
1.30 |
1.30 |
1.30 |
|
|
800-960 mhz |
1.30 |
1.30 |
1.30 |
1.30 |
|
|
1700-2025 mhz |
1.40 |
1.30 |
1.30 |
1.30 |
|
|
2110-2170 mhz |
1.40 |
1.30 |
1.30 |
1.30 |
|
|
2300-2400 mhz |
1.40 |
1.30 |
1.30 |
1.30 |
|
|
2500-2700 mhz |
1.40 |
1.30 |
1.30 |
1.30 |
|
|
Ib Leeg khoov rau vojvoog (hli) |
75 |
150 |
200 |
400 |
|
|
Rov qab khoov radius (hli) |
150 |
250 |
400 |
500 |
|
|
Dabtsi yog khoov Towerque (n • m) |
13.5 |
14.9 |
15.5 |
16.0 |
|
|
Tensile lub zog (n) |
1000 |
1490 |
1550 |
3300 |
|
|
Pom zoo ruaj ruaj (m) |
0.8-1 |
0.8-1 |
0.8-1 |
0.8-1 |
|
|
Nrug rau phab ntsa min (hli) |
50 |
50 |
50 |
50 |
|
|
Kev ntsuas kub (degree) |
Pe |
-40~+60 |
-40~+60 |
-40~+60 |
-40~+60 |
|
Lszh |
-20~+60 |
-20~+60 |
-20~+60 |
-20~+60 |
|
|
Kev Ua Haujlwm Kub (Qib) |
Pe |
-55~+85 |
-55~+85 |
-55~+85 |
-55~+85 |
|
Lszh |
-30~+80 |
-30~+80 |
-30~+80 |
-30~+80 |
|
|
Ua attenuation(dB/100m) & Coupling Poob(2m,50%/95%) @ 20 degree |
||||
|
Zaus, MHz |
DB DB |
DB DB |
DB DB |
DB DB |
|
75 |
/ / |
1.1 64/75 |
0.7 62/73 |
0.6 62/73 |
|
100 |
/ / |
1.2 60/70 |
0.8 58/68 |
0.7 58/68 |
|
150 |
/ / |
1.5 66/78 |
1.0 64/74 |
0.9 64/74 |
|
350 |
/ / |
2.4 76/88 |
1.6 76/88 |
1.3 76/90 |
|
450 |
/ / |
2.8 82/89 |
1.9 80/90 |
1.5 78/88 |
|
800 |
7.2 69/73 |
3.8 71/74 |
2.6 71/74 |
2.1 70/73 |
|
900 |
7.7 68/72 |
4.1 69/72 |
2.8 69/72 |
2.3 69/72 |
|
960 |
8.3 68/71 |
4.3 69/71 |
2.9 68/71 |
2.4 68/71 |
|
1800 |
11.5 65/68 |
6.5 64/68 |
4.5 64/68 |
3.6 64/68 |
|
1900 |
12.3 66/68 |
6.9 64/68 |
4.7 64/68 |
3.9 63/68 |
|
2000 |
12.8 67/70 |
7.2 63/67 |
5.0 63/67 |
4.1 63/67 |
|
2100 |
/ / |
7.5 63/68 |
5.2 63/68 |
4.3 63/68 |
|
2400 |
15.5 63/66 |
8.5 62/66 |
6.2 62/66 |
5.0 62/66 |
|
2600 |
16.1 64/67 |
8.9 61/65 |
7.0 61/65 |
5.6 61/65 |
|
2620 |
17.2 65/68 |
9.4 62/66 |
7.2 61/65 |
5.8 61/65 |
|
2700 |
18.0 65/69 |
10.5 62/66 |
7.6 62/66 |
6.3 60/66 |
Pob ntawmLeaky Feeder Cable
Hoobkas ntawm50 OHM Leaky Cable
Peb muaj kev sib cav sib ceg 150000㎡ cov kws tshaj lij, thiab txhawb kev hloov kho ntawm cov kev qhia tshwj xeeb, thov hu rau kuv lossis sau cov lus.
